YCPQA-9901 Power Quality Analyzer
YCPQA-9901 Power Quality Analyzer is used to long-term or short-term on-line monitor voltage, current and power of the power grids, providing reliable monitoring data for making harmonic pollution reduction approaches for the power grid.
Selling price:
$0.00
Product Detail
Mian function
■ With various operation interfaces, YCPQA-9901 can measure 3P3W and 3P4W Voltage, Current, Frequency, Phase angle,
■ Power factor, Active power, Reactive power, Apparent power
■ Real-time measure and analyze harmonics, and 2 ~岱ha伽onics content and distortion also can be measured;
■ Display the real-time waveform of each phase,
■ Display real-time vector diagram, easy to check the wiring on-site, can identify wiring automatically;
■ Measure various power quality phenomenons, record, and analyze power quality events
Main features
■ 5.6'inch, 640x480 dot-matrix LCD, displays the operation hint and measured data;
■ Large capacity Li-battery, the continuous working time more than 7 hours;
■ YCPQA-9901 is fully compliant with the !EC 61000-4-30, EN 50160:2004
■ Real-time measure and record basic electric parameters, harmonic, flicker, Voltage/Current unbalance ratio, swell/dip, over-voltage, under-voltage, peak voltage,
■ Set various triggering conditions to record failure waves and events,
■ Self-protection function, safe and reliable,
■ The weight of the machine is less than 5Kg, compact and lightweight, easy to carry;
■ Support calibrating by user self
